• Wilwood D52 Rear Caliper Kit - Red 1.25 / 1.25in Piston 1.04in Rotor - #140-11293-R
1 1

Wilwood

Wilwood D52 Rear Caliper Kit - Red 1.25 / 1.25in Piston 1.04in Rotor - #140-11293-R

Wilwood D52 Rear Caliper Kit - Red 1.25 / 1.25in Piston 1.04in Rotor - #140-11293-R

$ 484.13
$ 532.55 $ 484.13
✓ In Stock • Ready to Ship
Shipping calculated at checkout.

Wilwood's D52 Rear Caliper Kit offers a matching rear replacement option for our front D52 calipers. It is a direct bolt-on 2-piston replacement for the factory original single piston calipers used on many custom application rears. With the added benefit of smaller rear piston sizing (2.46 sq-inches of area) not normally available in OEM calipers, for correct front and rear bias. Forged billet aluminum bodies, stainless steel pistons, and competition style high-temperature seals put an end to the rust, bore pitting, and seal failures that plague the OE caliper design. D52 calipers provide low-maintenance performance and a huge weight savings with high temperature reliability for the street and track. D52 calipers mount in the stock location over stock rotors, use the original style OE D52 brake pads and an OE 7/16-20 banjo bolt brake line mounting. Calipers can be used with most wheels that clear the OE calipers. Kits contain Wilwood’s hardened slide pins and BP-10 high friction pads. Matching rear calipers are also available for custom installations.

  • Fitment & Installation Details
  • D52 Rear Caliper Kit Assembly Schematic
  • Rear End / Axle Housing Flange

Confirm The Configuration!

Confirm Offset Measurement!

Axle Flange Cross-Section

Search Rear Kits By Rear End/Axle Offset

Check the diagram above and verify this measurement. This kit may be available in several different offsets.

  • Please call Wilwood with any questions:
  • Compatible Vehicles for this Brake Kit
  • This Brake Kit is Compatible with the Following Vehicle Makes:

Note: Kit may fit other vehicles, call Wilwood Sales⁄Tech Support at (805) 388-1188 for more information.

For a Complete Listing including ALL Makes, Models and Years, Please click on the Axle Offset.

  • Kit Components & Specifications
  • D52 Caliper - Red Powder Coat
  • Hat Offset Dimension (in):

Details

  • Manufacturer Part Number: 140-11293-R

Universal / application-specific component — please verify specifications and compatibility with your brake system before ordering.

WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Image shown is a representative product from the same Wilwood series; it is for reference only and the actual product will differ. Refer to the part number and specifications above.

Manufacturer's Warranty — Wilwood

Wilwood Engineering publishes a formal Disclaimer of Warranty for its disc brakes, hubs, and racing components (datasheet DS-237). Because these parts are exposed to widely varying installation and operating conditions, Wilwood sells them “as is” and “with all faults,” and makes no warranty of any kind — expressed or implied, including no warranty of merchantability and no implied warranty of fitness for a particular purpose. Purchasers are expected to rely on their own skill and judgement to select the correct part, and it is the installer's responsibility to determine a component's suitability for the application. Racing equipment and brakes must be maintained and checked regularly for fatigue, damage, and wear. If a part arrives with a suspected manufacturing defect, contact us and we'll help you take it up with Wilwood.

Warranty terms are set by the manufacturer and may change. Contact us if you need help with a warranty claim.
